Specifications

・The above mentioned accuracy applies to sensors with an effective
stroke of 300mm or more.

◆associated controler
　analogue output:GYHC(Page.42-43)
　digital output:GYDC-05(Page.46-47)

Model No.

①Effective stroke
　　20mm-2000mm

②Thread dead zone
　　S:50mm(STD)
　　□:□mm(option)(specified by customers)

③Tip dead zone
　　S:70mm(STD)
　　・S (STD length) depends on the selected magnet or float in ⑤.

□:□mm(option)(specified by customers)

④Thread/Rod diameter
　　P8 :O-ring, rod Φ8(STD)

⑤Associated magnet
　　＜magnet＞
　　MG178 :No.178(STD)
　　M0SPM :No.ΦSPM
　　M0LPM :No.ΦLPM
　　M2PN :No.2PN
　　MG□ :other magnet

⑥Cable connection
　　G□F:pigtail / cable end : free
　　G□A:pigtail / cable end : with connector for relay
　　(□:cable length(m))

⑦Output
　　00:depends on external controller

Dimensions

Probe		Connection

・Material probe head:SS304, probe rod:SS304
・For magnet, standard is No.178.
・For others, select one from group GG on page 75.
